Kidd

ID # 26150770

Kidd Bale Shredders

Videos
Call for Price
Overview

Bale Shredders 450 and 850 easily handles straw, haylage, clamp grass and maize silage. It’s compact but with surprising large capacity for 2 round bales up to 6ft diameter. Material can be directed to exactly where it is needed with less waste.

Kidd has launched a new range of Bale Shredders to compliment the 450 & 850 Bale Shredder range. A new smaller and lighter range of Bale Shredders is now available.

The 330 is the only machine on the market that can be factory built for Shredding or Twin Chopping. Can be converted by a distributor. The shorter chop length can be varied in length. On most other machines it cannot.

– The Chopping mechanism on the 330 can be withdrawn for service and inspection. On other machines they cannot300TC with tractor
– All chopping blades on the 330 are protected against stones and other objects
– The 330 is the only machine that will shred or twin chop straw and handle green material
– The unique drum concave design throws less stones
– Chopping on the 330 can be done only on the beater against the concave
– The top bank of knives gives a short chop and reduces process time
– The 330 has an all welded body that will withstand vibration and tractor knocks
– The swivel chute on the 330 is lower get under buildings overhangs

With the increasing demand from end users for a machine that can process straw, hay, silage or haylage with little or no adjustment for feeding, chopping or bedding, the 475T TC – the first of its kind on the market. The 475T TC Bale processor and Straw chopper can handle 2 round bales or 2 big square bales (80cms x 120cms) side by side.300TC with tractor

The smart conveyor reduces process time, hang-ups and evens the material flow over the beater, into the chopping mechanism and fan. Crop flow is maximised at all times without blocking or stopping. Set the 475 running and the smart conveyor controls the process – all controlled at the touch of a button!

The 475 will shred and spread un-chopped straw for bedding, or when the chopping mechanism is selected will give an infinitely variable short chop length from 30 – 60mm which is suitable for bedding or a TMR ration.

The 475 bale processor is a versatile machine that can handle all straw types for bedding and feeding and any green material for feeding, it comes with a high capacity fan, heavy duty flails and chopping mechanism, 3 stage swivel chute, in-cab electric controls, wide angle PTO and smart conveyor.



Specifications
Model
Bale Shredders
Category Name
Agriculture
Sale Type
New
Manufacturer
Kidd
Width
2.25M
Brakes
Std
Height
2.65M
Length
5.96M
Weight
3000Kg
Wheels
12.5 / 75x 15.3
Beaters
2
Tractor
90HP
Capacity
8.5m 3
Wheel Track
1.90M
features
Round or square bales are distributed with an even flow of material.Round or square bales are distributed with an even flow of material.
Loose silage is evenly distributed.Loose silage is evenly distributed.
Wide body for greater capacity.Kidd Bale Shredder 8 300x168
Will take the largest bales produced, round or square.Kidd Bale Shredder 7 300x168
The 300 bale Shredder is mounted for close manoeuvrability in tight buildings but has all the punch of the trailed 450.The 300 bale Shredder is mounted for close manoeuvrability in tight buildings but has all the punch of the trailed 450.
Feeding silage over a barrier.Feeding silage over a barrier.
Beater fan combination evenly feeds silage.Beater fan combination evenly feeds silage.
450 TC will shred straw unchopped for animal bedding or at the touch of switch chop straw short for inclusion into a feed ration or for cubical bedding.450 TC will shred straw unchopped for animal bedding or at the touch of switch chop straw short for inclusion into a feed ration or for cubical bedding
Reliable chain drive for tub.Reliable chain drive for tub.
330 mounted for shredding and variable length choppingKidd Bale Shredders
Beater concave with variable louvres to adjust chop lengthKidd Bale Shredders
Beater for shredding or choppingKidd Bale Shredders
The 850 with large capacity will handle baled straw, baled or loose silage.The 850 with large capacity will handle baled straw, baled or loose silage.
The large capacity 850 has twin beaters and will hold 8.5cum silage, 4 round bales or 2 large square bales.The large capacity 850 has twin beaters and will hold 8.5cum silage, 4 round bales or 2 large square bales.
The extending door of the 850 allows easy loading and increases capacity, for 2 x large square bales or 4 x round bales.The extending door of the 850 allows easy loading and increases capacity, for 2 x large square bales or 4 x round bales.
